The Suntest XLS+ is used to check for property changes of materials and products caused by sunlight, temperature and moisture in a short period of time. The aging which, outdoor or indoor, may take place over months or years, such as fading, yellowing or loss of strength, can often be simulated within weeks inside a Suntest.
The Atlas Suntest XLS+ Â is an advanced bench-top xenon tester with state-of-the-art UV-control, designed for the reliable R&D testing of new materials for various end use environments as well as for standardized quality control. The Suntest XLS+ fits into any lab and comes standard with a 1100 cm2 exposure area, suiting multiple flat or 3D samples.
The Suntest XLS+ is equipped with a microprocessor-based controller for measurement and regulation and works with software-controlled testing programs.
Technical specifications:
Voltage: 220-240 V
Current: 20.5 A
Maximum power consumption: 3.1 kW
Nominal rating of Xenon lamp: 2.2 kW
Controlled irradiance: 300 to 800 nm
Maximum exposure area: 1089 cm
BST measuring range: 30 to 90°
Time: 1 to 999 minutes
Cooling requirement:
Lamp cooling: 250 m³/h
Air conditioner: 340 m³/h
Noise emission:
Noise level: < 75 dB(A)
Ambient conditions:
Room temperature: 18°C to 25°C
Relative humidity: max. 70%
Air pressure: 700 – 1060hPa
Outer dimensions (W) x (D) x (H):Â 930 x 500 x 480 mm
Sample table dimensions (W) x (D):Â 330 x 330 mm
Specimen surface area: about 1,000 cm2
Weight: 80 kg
