All Lauda KS thermostats offer operating temperature of -30 °C onto 300 °C.
Laboratory thermostats operate with liquids (operating medium, heat transfer fluid) which serve for energy transfer to the product to be thermostated.
The thermostated products can be immersed in the thermostatic bath (bath thermostat), or placed in an external open bath whose liquid is circulated by the pump of the thermostat. When operating as circulator, the thermostatic liquid is pumped through an external heat exchanger.
Technical specifications:
Voltage: 220-240 V
Heater power: 3 kW
Operating temperature range: -30 °C … 300 °C
Working temperature range with water cooling: 50 °C … 300 °C
Working temperature range with water cooling, water 15 °C: 20 °C … 300 °C
Ambient temperature range: 5 °C … 40 °C
Temperature variation at 70 °C in the bath: +/- 0,01 °C
Filling volume: 4,5 … 7,5 liter
Pressure / suction: 24 / 18 l/min
Pump pressure (max): 0,5 / 0,34 bar
Outer dimensions (W) x (D) x (H): Â 200 x 450 x 450 mm
Bath opening dimensions (W) x (D): 150 x 130 mm
Bath depth: 200 mm
Weight: 14 kg
