This detector is designed with a double temperature controlled house to improve the warm up time for detector stabilization. Featuring three modes of operation, the RID-10A can be used for highly sensitive analytical HPLC, semi-preparative HPLC, and large-scale preparative HPLC.
Technical specifications:
Voltage: 220-240 V
Measuring system: deflection type
Range of refractive index: 1 to 1.75
Measuring range: 0.25 x 10-4 to 512 x 10-6 RIU FS, Selectable in 12 steps
Linearity: 8 x 10-4 RIU or higher
Cell volume: 10 µL
Material in contact with liquid: SUS316, quartz, Teflon
Response: 3 step selection: FAST, STD and SLOW
Controlled temperature of cell: 35°C (Thermal fuse 70°C)
Outer dimensions (W) x (D) x (H): 270 x 420 x 130 mm
Weight: 12 kg
